KS502
CLAM SHELL (PEN DRIVE) ASSEMBLY MACHINE

KS502 CLAM SHELL (PEN DRIVE) ASSEMBLY MACHINE

+ Identity

■ Simply operation & real time error message.

■ In the operation, anything jams or insert error, it will be detected by sensor and stop automatically then show on the screen.

■ No good product auto reject to no good area.

■ Clamshell & Insert refill no need stop machine; it can save time & rise up operation rate.

■ Clamshell not closed well, real time show on the screen.

■ This model installed clear door, it suitable to check the status and more safety by operator.

■ This machine can connect flash & adapter loader. (option)

+ Dimension, Capacity & Station

01. Pen drive area / 50 PCS

02. Clamshell area / 130 PCS

03. Insert area / 6 PAGES / 500 PCS

04. Clamshell closer

05. No good collect

KS502 CLAM SHELL (PEN DRIVE) ASSEMBLY MACHINE
